DEHNguard M YPV SCI 150

DEHNguard M YPV SCI 150 (952513)

Modular and pluggable multipole arrester
for use in photovoltaic systems up to 150 V d.c.
with three-step d.c. switching device, width: 3 modules
Fault indication
Type 2 SPD according to EN 50539-11
For use in accordance with IEC 60364-7-712
Safe electrical isolation in the protection module
Max. PV voltage: <= 150 V d.c.
Total discharge current: 40 kA
Voltage protection level: <= 0.8 kV
Short-circuit current rating Iscpv: 10 kA

Please note:
This item will be ordered on an order related basis.
Cancellation/return and change of the
agreed conditions is excluded!
