N. articolo: 7900400097
DEHNguard MP YPV 1500 FM
surge arrester type II
Larghezza54 mm
Altezza90 mm
Tipo di scaricatoreTipo II
Lato connessioneLato DC
Peso0,328 Kilogramm
Profondità66 mm
N. di registrazione RAEE DE11890845
Descrizione Prodotto
Surge arrester DEHNguard MP YPV 1500 FM
Multipole, modular, pluggable
Photovoltaic arrester
with double push-in connection terminal suitable for
stub and through-wiring
up to 1500 V DC, width 3TE
Defect indicator
With remote signalling contact
Type 2 according to EN 61643-31
Applicable according to IEC 60364-7-712
Maximum PV voltage: <= 1500 V dc
Total discharge surge current: 40 kA
Protection level: <= 5 kV
Short-circuit withstand voltage Iscpv: 10 kA
Multipole, modular, pluggable
Photovoltaic arrester
with double push-in connection terminal suitable for
stub and through-wiring
up to 1500 V DC, width 3TE
Defect indicator
With remote signalling contact
Type 2 according to EN 61643-31
Applicable according to IEC 60364-7-712
Maximum PV voltage: <= 1500 V dc
Total discharge surge current: 40 kA
Protection level: <= 5 kV
Short-circuit withstand voltage Iscpv: 10 kA
