Huawei LUNA2000-5-E1

The Huawei LUNA2000-5-E1 is a modular high-voltage battery module with 5 kWh of usable energy and LiFePO₄ cell technology. It serves as a scalable component for high-performance storage solutions and enables system capacities from 5 kWh to 21 kWh per unit, as well as the parallelization of multiple systems. The integrated optimization electronics ensure high usable energy, while the robust IP66 housing and wide operating temperature range allow for both indoor and outdoor use. The module is compatible with single-phase and three-phase hybrid inverters of the SUN2000 series and is suitable for professional commercial installations.

• TechnologyThe battery module utilizes lithium iron phosphate cells and features a multi-level protection concept that safeguards against over- and undervoltage, overcurrent, and temperature deviations. The design offers high thermal stability and safe operational management even at 100% depth of discharge. Certifications such as VDE2510-50, IEC 62619, and UN38.3 emphasize its suitability for demanding applications. A specific product warranty cannot be clearly verified and is therefore not mentioned.
• ConnectivityFor system integration, RS485, FE, and CAN are available, allowing the battery module to be flexibly integrated into hybrid storage systems. Automatic device recognition via the FusionSolar app simplifies commissioning and supports efficient monitoring. The internal optimizer structure also ensures precise power control at the module level.

  Relevant Interfaces
  • RS485, FE, and CAN communication for flexible system integration
  • Automatic detection and configuration via FusionSolar app
  • Module-based optimizer architecture for efficient power regulation
• Installation ConceptThe LUNA2000-5-E1 uses a stackable module design that allows for fast assembly and flexible expansion. With compact dimensions and a weight of approximately 68 kg, space-saving installation is achievable. The module can be operated indoors or outdoors, supported by IP66 protection and natural convection cooling. The concept is ideal for scalable project setups.

  Installation Advantages
  • Stackable modular system for fast installation
  • Flexible indoor and outdoor mounting thanks to IP66 housing
  • Natural convection cooling without additional maintenance effort
• SustainabilityThe LiFePO₄ technology used impresses with a long service life and high cycle stability, which reduces resource consumption over the life cycle. The modular design facilitates repair and expansion, sustainably optimizing overall utilization. Additionally, energy-efficient operation contributes to minimizing losses in daily use.
