Numero di articolo: 3002000072
Goodwe GW50KS-MT SMT 15A
Inverter trifase AFCI
Prices and availabilities visible only after login
Merkmale
Profondità [mm]
220
Larghezza [mm]
520
Altezza [mm]
660
Peso [kg]
55
Tipo di connettore CC
MC4
Tensione massima CC [V]
1100
AC-potenza nominale [VA]
50000
CC-potenza nominale [W]
50000
Efficienza massima () [%]
98,6
Numero di fasi di immissione in rete
3
Numero di trackers MPP
5
Tipo di inverter
Di rete
Protezione IP
65
N. di registrazione RAEE DE
33154372
Descrizione
WLAN/RS485
DC-circuit breaker
according to VDE AR-N-4105:2018-11
for grid connection
Degree of protection: IP65
euro efficiency: 98,1%
height x width x depth 660/520/220 mm
nominal power: 50000W AC
max. DC voltage: 1100V
DC-circuit breaker
according to VDE AR-N-4105:2018-11
for grid connection
Degree of protection: IP65
euro efficiency: 98,1%
height x width x depth 660/520/220 mm
nominal power: 50000W AC
max. DC voltage: 1100V
max. usable module string current: 15A
without display
5 years warranty
up to 20 years optional
Please note the country-specific service & warranty conditions of the manufacturer.
Attention, if the inverter is operated in a system
where more than 1000V DC voltage may occur,
then the enclosed MC4 field plugs and sockets must not be used.
In this case please use Evo2 plugs or sockets.
without display
5 years warranty
up to 20 years optional
Please note the country-specific service & warranty conditions of the manufacturer.
Attention, if the inverter is operated in a system
where more than 1000V DC voltage may occur,
then the enclosed MC4 field plugs and sockets must not be used.
In this case please use Evo2 plugs or sockets.
